3kw hybrid solar inverter
BSSI-V Series (2.2KW/3.2KW/4.2KW/6.2KW/7KW/10.2KW)Key Features
●Pure sine wave solar inverter(on/off Grid)
●Programmable supply priority for PV, battery or Grid
●High PV input voltage range(55~450VDC)
●Built-in Max 80A (3KW & 6.2KW)MPPT solar charge
●Compatible with lithium-ion battery
●Support BMS communication with Lithium battery
●Smart battery charge design to optimize battery life
●Overload, high temperature, inverter output short circuit protection
●Cold start function
●Intelligent fan speed adjustment
●Built-in anti-dust kit for harsh environment(3200VA/6200VA)
●WIFI available for IOS and Android (optional)
Description
In the field of green energy, the 3kw hybrid solar inverter is a highly practical and flexible device. It uses pure sine wave technology, with AC230V output and 24V input voltage. This inverter also has 80A MPPT (maximum power point tracking) technology, which can effectively improve the power generation efficiency of the photovoltaic system. At the same time, it also supports programmable power supply priority of photovoltaic, battery or grid, making energy utilization more flexible. In addition, this inverter can also communicate with Battery Management System and lithium batteries to achieve more intelligent energy management. It also has a higher photovoltaic input voltage range 55VDC~450VDC to meet the needs of different photovoltaic systems. It can be said that this Busbyr 3000w hybrid inverter has rich functions and a wide range of application scenarios, and has played an active role in promoting the development and application of renewable energy.
Specification
MODEL | BSSI-V-B3200 | BSSI-V-B7000 |
Rated Power | 3200VA/3000W | 7000VA/6200W |
INPUT | ||
Voltage | 230VAC | |
Selectable Voltage Range | 170-280VAC（for personal computers) | |
Frequency Range | 50Hz/60Hz(Auto aensing) | |
OUTPUT | ||
AC Voltage Regulation (Batt.Mode) | 230VAC±5% | |
Surge power | 6400VA | 14000VA |
Transfer Time | 10ms(for personal computers) | |
Wave form | Pure Sine Wave | |
BATTERY & AC CHARGER | ||
Battery Voltage | 24VDC | 48VDC |
Floating Charge Voltage | 27VDC | 54VDC |
Overcharge Protection | 31VDC | 61VDC |
Maximum Charge current | 80A | 80A |
SOLAR CHARGER | ||
MAX .PV Array Power | 3000W | 6000W |
MPPT Range @Operating Voltage | 55-450VDC | |
Maximum PV Array Open Circuit Voltage | 450VDC | |
Maximum Charging current | 80A | 110A |
Maximum Efficiency | 98% | |
PHYSICAL | ||
Dimension. D*W*H(mm) | 405×286×98MM | 423×310×106MM |
Net Weight (kgs) | 5Kg | 8.0Kg |
Communication Interface | RS232/RS485（Standard） | |
OPERATING ENVIRONMENT | ||
Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
Operating Temperature | -10°C to 55°C | |
Storage Temperature | -15°C to 60°C | |
